The Strain Gauge Load Cell is a precision measurement device designed to provide highly accurate force and weight readings in a variety of industrial and scientific applications. Constructed from premium materials such as alloy steel or alloy aluminum, this load cell combines durability with excellent mechanical performance, making it suitable for use in demanding environments. The choice of alloy steel or alloy aluminum ensures that the load cell can withstand heavy loads and resist corrosion, while maintaining its structural integrity over time.
At the heart of this load cell’s functionality are the advanced Strain Gauges integrated into its design. These Resistance Strain Gauges are meticulously bonded to the surface of the load cell, allowing them to detect minute deformations caused by applied forces. When a force is applied, the strain gauges experience a slight change in electrical resistance proportional to the strain, which is then converted into an electrical signal that can be measured and interpreted. This technology provides a reliable and highly sensitive means of capturing force data with exceptional accuracy.
The Strain Gauge Load Cell employs Linear Strain Gauges specifically engineered to deliver consistent, proportional output signals corresponding to the applied load. The linearity of these strain gauges ensures that the output remains stable and predictable across the entire measurement range, which is crucial for applications requiring precise calibration and repeatability. This linear response minimizes measurement errors and allows for seamless integration with digital readout systems and data acquisition equipment.
One of the key performance characteristics of this load cell is its compensated temperature range, which spans from -10℃ to 50℃. This compensation ensures that the load cell maintains its accuracy and stability despite fluctuations in ambient temperature. Temperature variations can often cause shifts in zero balance and output sensitivity, but the built-in compensation mechanisms in this load cell effectively minimize these effects, providing reliable measurements even in environments where temperature changes are common.
The temperature effect on zero balance is remarkably low in this strain gauge load cell, with a specification of ≤0.02% F.S. per 10℃. This means that any drift in the zero point of the measurement due to temperature changes is minimal, ensuring that the baseline measurement remains consistent. This feature is especially important in precision weighing and force measurement applications where even slight deviations can lead to significant errors in data interpretation.
Repeatability is another critical parameter where this load cell excels. With a repeatability rating of ≤0.01% F.S., the device guarantees that consecutive measurements under identical conditions will produce nearly identical results. This high level of repeatability is essential for quality control processes, research experiments, and any application where consistent measurement data is vital for decision-making and analysis.
Hysteresis is also tightly controlled in this product, with a maximum hysteresis of ≤0.02% F.S. Hysteresis refers to the difference in output when the load is applied and then removed, and minimizing this effect is crucial to ensure that the load cell returns to its original zero state without residual error. Low hysteresis enhances the reliability and accuracy of measurements, particularly in dynamic loading scenarios where forces are frequently applied and released.
Overall, the Strain Gauge Load Cell represents a sophisticated fusion of advanced resistance strain gauge technology and robust material engineering. Its use of high-quality alloy steel or alloy aluminum, combined with temperature compensation, low temperature-induced zero shifts, excellent repeatability, and minimal hysteresis, makes it an ideal choice for a wide range of precision measurement tasks. Whether deployed in industrial weighing systems, structural testing, or laboratory research, this load cell delivers dependable performance and accurate data, ensuring that users can trust their measurements every time.
| Temperature Effect On Zero | ≤0.02%F.S./10℃ |
| Insulation Resistance | ≥5000 MΩ (100VDC) |
| Mounting Type | Screw Mount |
| Features | High Precision, Good Performance |
| Material | Alloy Steel or Alloy Aluminum |
| Capacity | 1-30t |
| Compensated Temperature | -10℃ to 50℃ |
| Hysteresis | ≤0.02%F.S. |
| Linearity | 0.2% F.S. |
| Repeatability | ≤0.01%F.S. |
The Top Sensor CL-04 Strain Gauge Load Cell is an advanced measurement device widely used in various industrial and commercial applications requiring precise force and weight detection. Manufactured in China, this product boasts a capacity range from 1 to 30 tons, making it suitable for a broad spectrum of load measurement scenarios. Its robust construction from high-quality alloy steel or alloy aluminum ensures durability and reliability even under harsh working conditions.
One of the key features of the CL-04 load cell is its integration of Linear Strain Gauges and Full Bridge Strain Gauges, which provide highly accurate and stable output signals. These resistance strain gauge elements contribute to a repeatability of ≤0.01%F.S., ensuring consistent performance over numerous measurement cycles. Additionally, the load cell exhibits excellent insulation resistance of ≥5000 MΩ at 100VDC, which enhances signal integrity by minimizing electrical noise and interference.
This strain gauge load cell is ideal for applications in weighing systems, industrial automation, material testing machines, and structural health monitoring. Its ability to accurately measure loads in real-time makes it indispensable in quality control processes across manufacturing plants. For example, it can be used in conveyor belt scales, hopper scales, and tank weighing systems where precise load data is critical for operational efficiency.
The CL-04 also handles temperature variations effectively, with a temperature effect on zero of ≤0.02%F.S./10℃, making it reliable for use in environments with fluctuating temperatures. Its robust packaging in carton boxes and pallets ensures safe shipment, with a minimum order quantity of 20 pieces and a monthly supply capacity of 2000 pieces. Delivery typically takes between 20 to 25 days, with payment terms set as T.T in advance.
In summary, the Top Sensor CL-04 Strain Gauge Load Cell is perfectly suited for industries requiring precise load measurement combined with durability and reliability. Whether integrated into complex weighing systems or used in standalone force measurement applications, its use of resistance strain gauges, including linear and full bridge types, ensures accurate and repeatable performance, making it an excellent choice for engineers and system integrators worldwide.
Q1: What is the brand and model number of the strain gauge load cell?
A1: The brand name is Top Sensor and the model number is CL-04.
Q2: Where is the Top Sensor CL-04 strain gauge load cell manufactured?
A2: It is manufactured in China.
Q3: What is the minimum order quantity for the CL-04 load cell?
A3: The minimum order quantity is 20 pieces.
Q4: How is the CL-04 load cell packaged for shipment?
A4: The load cells are packaged in carton boxes and pallets to ensure safe delivery.
Q5: What are the delivery time and payment terms for ordering the CL-04 load cells?
A5: The delivery time is typically 20-25 days and the payment terms are T.T (telegraphic transfer) in advance.
Q6: What is the monthly supply capacity for the Top Sensor CL-04 strain gauge load cells?
A6: The supply ability is 2000 pieces per month.
