The Strain Gauge Load Cell is a highly precise and reliable force measurement device designed to meet the most demanding industrial and laboratory applications. Utilizing advanced Full Bridge Strain Gauges technology, this load cell ensures exceptional accuracy and stability in various load sensing scenarios. The integration of Linear Strain Gauges and Foil Strain Gauges within the sensor structure provides superior performance, making it an ideal choice for precision weighing, force measurement, and structural testing.
One of the standout features of this Strain Gauge Load Cell is its minimal hysteresis, which is rated at ≤0.02% of full scale (F.S.). This low hysteresis value means that the load cell delivers consistent output signals when subjected to load and unloading cycles, ensuring reliable measurements without significant lag or deviation. This characteristic is vital for applications requiring high repeatability and accuracy in dynamic environments.
Repeatability is another critical parameter where this load cell excels, boasting a repeatability of ≤0.01% F.S. This exceptional repeatability guarantees that the load cell will produce nearly identical results under the same loading conditions, which is essential for quality control processes, calibration tasks, and any application where consistent measurement is paramount. The combination of low hysteresis and outstanding repeatability confirms the load cell’s capability to deliver dependable and precise data over its operational lifespan.
The device also maintains excellent linearity, with a specification of 0.2% F.S. Linearity refers to how closely the output signal corresponds to the actual applied load throughout the measurement range. A linearity of 0.2% F.S. ensures that the load cell output is proportional to the force applied, minimizing non-linear errors and simplifying signal processing. This feature is particularly beneficial in automated systems and digital readouts, where straightforward interpretation of sensor data reduces complexity and enhances overall system reliability.
Designed to operate reliably across a broad temperature range, the Strain Gauge Load Cell functions effectively from -10 ℃ to 60 ℃. This wide operating temperature range allows the load cell to be employed in various environments, from controlled indoor laboratory settings to more challenging industrial conditions where temperature fluctuations are common. The load cell’s robust design and temperature tolerance make it adaptable to diverse applications without compromising measurement accuracy or sensor integrity.
The mounting type for this load cell is specifically designed for Screw Mount installation. This mounting method ensures secure and stable attachment to the structure or measurement setup, reducing mechanical noise and enhancing measurement accuracy. The screw mount design also facilitates easy installation and maintenance, allowing users to integrate the load cell into existing systems with minimal effort and maximum reliability.
At the core of this load cell’s sensing mechanism are the Full Bridge Strain Gauges, which provide a balanced Wheatstone bridge circuit configuration. This setup enhances sensitivity and compensates for temperature-induced variations, ensuring precise and stable output signals. The incorporation of Linear Strain Gauges further refines the sensor’s ability to measure strain accurately over its sensing elements, while the Foil Strain Gauges contribute to durability and environmental resistance, making the load cell suitable for long-term use in industrial applications.
In summary, the Strain Gauge Load Cell is a cutting-edge measurement device that combines advanced Full Bridge Strain Gauges, Linear Strain Gauges, and Foil Strain Gauges technologies to deliver superior performance. With ultra-low hysteresis (≤0.02% F.S.), exceptional repeatability (≤0.01% F.S.), and excellent linearity (0.2% F.S.), this load cell provides highly accurate and reliable force measurements. Its broad operating temperature range (-10 ℃ to 60 ℃) and screw mount installation design make it versatile and easy to integrate into various systems. Whether for industrial automation, material testing, or precision weighing, this Strain Gauge Load Cell offers the performance and durability needed to meet the highest standards in load sensing technology.
| Capacity | 1-30t |
| Insulation Resistance | ≥5000 MΩ (100VDC) |
| Material | Alloy Steel Or Alloy Aluminum |
| Compensated Temperature | -10℃ - 50℃ |
| Hysteresis | ≤0.02% F.S. |
| Mounting Type | Screw Mount |
| Operating Temperature | -10℃ - 60℃ |
| Temperature Effect On Zero | ≤0.02% F.S./10℃ |
| Linearity | 0.2 % F.S. |
| Features | High Precision, Good Performance |
The Top Sensor CL-04 Strain Gauge Load Cell, manufactured in China, is a highly reliable and precise measurement instrument designed for various industrial and commercial applications. With a capacity range from 1 to 30 tons, this load cell is ideal for scenarios requiring accurate force measurement and weight detection. Its screw mount type ensures secure and stable installation, making it suitable for integration into diverse machinery and testing setups.
One of the primary application occasions for the CL-04 load cell is in material testing laboratories, where Resistance Strain Gauge technology is employed to measure the deformation of materials under stress. This enables engineers and researchers to assess material properties and structural integrity. The load cell's excellent repeatability of ≤0.01%F.S. and high insulation resistance of ≥5000 MΩ at 100VDC guarantee consistent and reliable data output, essential for precise strain measurement using Strain Gauges.
Manufacturers in the automotive and aerospace industries also benefit from the CL-04 load cell when conducting component testing and quality control. The compensated temperature range of -10℃ to 50℃ allows the device to function accurately in varying environmental conditions, ensuring dependable performance during durability and fatigue testing of critical parts. Additionally, the Top Sensor CL-04 is widely used in industrial automation systems for weighing, force monitoring, and load measurement tasks, where its robust design and high supply ability of 2000 pieces per month support large-scale deployment.
In logistics and material handling, the CL-04 load cell is implemented in weighing scales and load monitoring equipment to provide precise weight measurements that enhance operational efficiency and safety. The product’s packaging in carton boxes and pallets facilitates safe transportation and storage, with a delivery lead time of 20-25 days and a minimum order quantity of 20 pieces. Payment terms of T.T in advance ensure smooth transaction processes.
In summary, the Top Sensor CL-04 Strain Gauge Load Cell is perfectly suited for applications requiring high precision and durability in force measurement. Its advanced Strain Gauges and Resistance Strain Gauge technology make it an indispensable tool across industries such as material testing, automotive, aerospace, industrial automation, and logistics. This versatility, combined with reliable performance and efficient supply, positions the CL-04 as a preferred choice for professionals seeking trustworthy load measurement solutions.
Q1: What is the brand and model number of this strain gauge load cell?
A1: The strain gauge load cell is from the brand Top Sensor and the model number is CL-04.
Q2: Where is the Top Sensor CL-04 load cell manufactured?
A2: The Top Sensor CL-04 load cell is manufactured in China.
Q3: What is the minimum order quantity for the Top Sensor CL-04 load cell?
A3: The minimum order quantity for the Top Sensor CL-04 load cell is 20 pieces.
Q4: How is the product packaged for shipping?
A4: The Top Sensor CL-04 load cell is packaged in a carton box and pallet to ensure safe delivery.
Q5: What is the typical delivery time for an order of Top Sensor CL-04 load cells?
A5: The delivery time for the Top Sensor CL-04 load cells is typically 20-25 days.
Q6: What payment terms are accepted for purchasing the Top Sensor CL-04 load cell?
A6: Payment is accepted via T.T (telegraphic transfer) in advance.
Q7: What is the monthly supply capacity for the Top Sensor CL-04 load cell?
A7: The supply ability for the Top Sensor CL-04 load cell is 2000 pieces per month.
